4 results found for "small wheel loader"
  • New Generation 5 Ton Wheel Loader with Tier II Engine
    5 Ton Front Loading Machine Bucket Capacity: 3 m3 Operating Weight: 17100 kg Rated Power: 162 kw Model ITQ958 Specifications Operating weight 17,100 kg Rated load 5,000 kg Bucket capacity 3 m³ Overall length 7950mm Overall width 2870mm Overall height 3500mm Bucket width 3000mm Wheel base 3300mm Track base 2260mm Min. ground clearance 470mm Max. dumping height 3300mm Max.dumping reach 1400mm Performance Driving speed    Forward 1 0-11.5km/h Forward 2 0-38km/h Reverse 1 0-16km/h Grade ability 28° Hydraulic torque converter single stage,4elements Transmission planet-type Raise time ≤6.8s Total ≤12.5s Tire type 23.5-25   20pr Engine Engine model weichai wd10g220e23 cummins 6cta8.3-c215 Rated power 162kw Rated rotate speed 2000r/min Max. torque ≥745.3n.m Breakout force 145kn
  • Construction Machinery 5 Ton Front End Wheel Loader for Mining Road Use
    958H New Mining Road Wheel Loader Model ITQ958H Specifications Operating weight 17,100 kg Rated load 5,000 kg Bucket capacity 3 m³ Overall length 7950mm Overall width 2870mm Overall height 3500mm Bucket width 3000mm Wheel base 3300mm Track base 2260mm Min. ground clearance 470mm Max. dumping height 3300mm Max.dumping reach 1400mm Performance Driving speed    Forward 1 0-11.5km/h Forward 2 0-38km/h Reverse 1 0-16km/h Grade ability 28° Hydraulic torque converter single stage,4elements Transmission planet-type Raise time ≤6.8s Total ≤12.5s Tire type 23.5-25   20pr Engine Engine model weichai wd10g220e23 cummins 6cta8.3-c215 Rated power 162kw Rated rotate speed 2000r/min Max. torque ≥745.3n.m Breakout force 145kn
  • 3 Ton Heavy Duty Equipment Small Wheel Loader
    3 Ton Heavy Duty Equipment Small Wheel Loader  Bucket Capacity: 1.7 m3 Operating Weight: 10100 kg Rated Power: 92 kw Features: 1.electronic transmission  2.joystick controller  3.radio, driving recorder, reversing image; 4.suspension seat 5.air-conditioner heavy duty loader Specifications Model ITQ935 Specifications Operating weight 10,100 kg Rated load 3,000 kg Bucket capacity 1.7 m³ Overall length 7200 mm Overall width 2350 mm Overall height 3200 mm Wheel base 2850 mm Track base 1800 mm Min. ground clearance 450 mm Max. dumping height 3400 mm Max.dumping reach 1290 mm Performance Driving speed    Forward 1 0-8 km/h Forward 2 0-13.5 km/h Forward3 0-25 km/h Forward4 0-36 km/h Reverse 1 0-9.5 km/h Reverse2 0-30 km/h Grade ability 28° Transmission counter shaft Raise time ≤6.8 s Fuel tank 180 L Total ≤12.5 s Tire type 17.5-25  Engine Engine model Deutz WP6G125E22 Rated power 92 kw Rated rotate speed 2200 r/min Max. torque 500 n.m Breakout force 98 kn
  • Construction Machinery Small Front End Wheel Loader
    Construction Machinery Small Front End Wheel Loader 1. Humanized design 2. European-style appearance, luxurious interior cab. 3. Full glass cockpit door, wide field of vision 4. Brake pipe with protective cover 5. The unique external setting of the injector is convenient for concentrated oil injection. 6. Fine line design, reasonable pipeline layout, easy maintenance 7. Automatic leveling, reducing driver fatigue  Specification Model   920 Rated load kg 1800 Operation total weight kg 4700 Overall Length mm 5700 Overall Width mm 2000 Overall Height mm 2850 Spread of axles mm 2250 Wheelbase mm 2200 ground clearance mm 240 Bucket width mm 2000 Turning radius (tyre center) mm 4800 Turning radius (outside of bucket in transportation position) mm 5800 Max Working height mm 4000 Max unloading height mm 3500 max unloading distance mm 800 Max steering angle ° 38 Trinomial sum sec 10.5 Working hydraulic system pressure Mpa 18 Tyre   1670-20 Rated power (Yunnei)  kW 76 Rated power (Yunnei)  kW   Rated speed r/min 2200 Bucket capacity m³ 1 Bucket capacity(Long arm)option m³ 1 Max speed km/h 38 Forward gear I km/h 6.8 Forward gear II km/h 12 Rear gear I km/h 6.5 Rear gear II km/h 11.8 Max breakout force KN 120 Max traction KN 110 Max climbing ablity ° 29
