Construction Equipment 5 Ton Wheel Loader Bucket Capacity: 3 m3 Operating Weight: 17100 kg Rated Power: 162 kw Model ITQ958 Specifications Operating weight 17,100 kg Rated load 5,000 kg Bucket capacity 3 m³ Overall length 7950mm Overall width 2870mm Overall height 3500mm Bucket width 3000mm Wheel base 3300mm Track base 2260mm Min. ground clearance 470mm Max. dumping height 3300mm Max.dumping reach 1400mm Performance Driving speed    Forward 1 0-11.5km/h Forward 2 0-38km/h Reverse 1 0-16km/h Grade ability 28° Hydraulic torque converter single stage,4elements Transmission planet-type Raise time ≤6.8s Total ≤12.5s Tire type 23.5-25   20pr Engine Engine model weichai wd10g220e23 cummins 6cta8.3-c215 Rated power 162kw Rated rotate speed 2000r/min Max. torque ≥745.3n.m Breakout force 145kn

3 Ton Heavy Duty Equipment Small Wheel Loader  Bucket Capacity: 1.3-2.5 m3 Operating Weight: 10300 kg Rated Power: 92 kw Features: 1.electronic transmission  2.joystick controller  3.radio, driving recorder, reversing image; 4.suspension seat 5.air-conditioner heavy duty loader Specifications Model ITQ737K Specifications Operating weight 10,300 kg Rated load 3,000 kg Bucket capacity 1.3-2.5 m³ Overall length 7040 mm Outside width of tire 2310 mm Cab height 3200 mm Wheel base 2750 mm Wheel track 1865 mm Ground clearance 360 mm Min. turning radius with bucket at transporting position 6040 mm Turning radius, at outside of tire 5516 mm Performance Max. traveling speed, forward   36km /h Max. traveling speed, backward 29 km/h Forward 2 0-13.5 km/h Forward3 0-25 km/h Forward4 0-36 km/h Reverse 1 0-9.5 km/h Reverse2 0-30 km/h Grade ability 28° Transmission counter shaft Raise time ≤6.8 s Fuel tank 180 L Total ≤12.5 s Tire type 17.5-25  Engine Engine model Deutz WP6G125E22 Rated power 92 kw Rated rotate speed 2200 r/min Max. torque 500 n.m Breakout force 98 kn

6 Ton New Generation Cheap Wheel Loader Model ITQ968H Specifications Operating weight 19,500 kg Rated load 6,000 kg Bucket capacity 3.5 m³ Overall length 8380mm Overall width 3100mm Overall height 3560mm Bucket width 3170mm Wheel base 3350mm Track base 2360mm Min. ground clearance 470mm Max. dumping height 3300mm Max.dumping reach 1290mm Performance Driving speed    Forward 1 0-8.5km/h Forward 2 0-16.5km/h Reverse 1 0-8.5km/h Grade ability 28° Hydraulic torque converter single stage,4elements Transmission counter shaft Raise time ≤6.8s Total ≤12.5s Tire type 26.5-25  Engine Engine model WEICHAI WD10G270E201 Rated power 199kw Rated rotate speed 2000r/min Max. torque 920n.m Breakout force ≥200 kn

958H New Mining Road Wheel Loader Model ITQ958H Specifications Operating weight 17,100 kg Rated load 5,000 kg Bucket capacity 3 m³ Overall length 7950mm Overall width 2870mm Overall height 3500mm Bucket width 3000mm Wheel base 3300mm Track base 2260mm Min. ground clearance 470mm Max. dumping height 3300mm Max.dumping reach 1400mm Performance Driving speed    Forward 1 0-11.5km/h Forward 2 0-38km/h Reverse 1 0-16km/h Grade ability 28° Hydraulic torque converter single stage,4elements Transmission planet-type Raise time ≤6.8s Total ≤12.5s Tire type 23.5-25   20pr Engine Engine model weichai wd10g220e23 cummins 6cta8.3-c215 Rated power 162kw Rated rotate speed 2000r/min Max. torque ≥745.3n.m Breakout force 145kn

5 Ton Front Loading Machine Bucket Capacity: 3 m3 Operating Weight: 17100 kg Rated Power: 162 kw Model ITQ958 Specifications Operating weight 17,100 kg Rated load 5,000 kg Bucket capacity 3 m³ Overall length 7950mm Overall width 2870mm Overall height 3500mm Bucket width 3000mm Wheel base 3300mm Track base 2260mm Min. ground clearance 470mm Max. dumping height 3300mm Max.dumping reach 1400mm Performance Driving speed    Forward 1 0-11.5km/h Forward 2 0-38km/h Reverse 1 0-16km/h Grade ability 28° Hydraulic torque converter single stage,4elements Transmission planet-type Raise time ≤6.8s Total ≤12.5s Tire type 23.5-25   20pr Engine Engine model weichai wd10g220e23 cummins 6cta8.3-c215 Rated power 162kw Rated rotate speed 2000r/min Max. torque ≥745.3n.m Breakout force 145kn

5 Ton Heavy Duty Wheel Loader Bucket Capacity: 3 m3 Operating Weight: 17100 kg Rated Power: 162 kw Model ITQ958 Specifications Operating weight 17,100 kg Rated load 5,000 kg Bucket capacity 3 m³ Overall length 7950mm Overall width 2870mm Overall height 3500mm Bucket width 3000mm Wheel base 3300mm Track base 2260mm Min. ground clearance 470mm Max. dumping height 3300mm Max.dumping reach 1400mm Performance Driving speed    Forward 1 0-11.5km/h Forward 2 0-38km/h Reverse 1 0-16km/h Grade ability 28° Hydraulic torque converter single stage,4elements Transmission planet-type Raise time ≤6.8s Total ≤12.5s Tire type 23.5-25   20pr Engine Engine model weichai wd10g220e23 cummins 6cta8.3-c215 Rated power 162kw Rated rotate speed 2000r/min Max. torque ≥745.3n.m Breakout force 145kn

New Generation 6 Ton Wheel Loader  Bucket Capacity: 3.5 m3 Operating Weight: 19500 kg Rated Power: 199 kw 1.electronic transmission  2.joystick controller  3.radio, driving recorder, reversing image; 4.suspension seat 5.air-conditioner optional: 1.automatic lubrication system,rops/fops cabin ,plate-fin water tank ,enlarge water tank ; 2.fuel preheating system,radial tire,quick hitch; Model ITQ968 Specifications Operating weight 19,500 kg Rated load 6,000 kg Bucket capacity 3.5 m³ Overall length 8380 mm Overall width 3100 mm Overall height 3560 mm Bucket width 3170 mm Wheel base 3350 mm Track base 2360 mm Min. ground clearance 470 mm Max. dumping height 3300 mm Max.dumping reach 1290 mm Performance Driving speed    Forward 1 0-8.5 km/h Forward 2 0-16.5 km/h Forward3 0-25 km/h Forward4 0-42 km/h Reverse 1 0-8.5 km/h Reverse2 0-16 km/h Grade ability 28° Transmission counter shaft Raise time ≤6.8 s Fuel tank 230 L Hydraulic tank 270 L Total ≤12.5 s Tire type 26.5-25  Engine Engine model WEICHAI WD10G270E201 Rated power 199 kw Rated rotate speed 2200 r/min Max. torque 920 n.m Max. traction force ≥185 KN Breakout force ≥200 kn

5 Ton Construction Machinery 3 cubic wheel loader Bucket Capacity: 3 m3 Operating Weight: 17100 kg Rated Power: 162 kw Model ITQ958 Specifications Operating weight 17,100 kg Rated load 5,000 kg Bucket capacity 3 m³ Overall length 7950 mm Overall width 2870 mm Overall height 3500 mm Bucket width 3000 mm Wheel base 3300 mm Track base 2260 mm Min. ground clearance 470 mm Max. dumping height 3300 mm Max.dumping reach 1400 mm Performance Driving speed    Forward 1 0-11.5 km/h Forward 2 0-38 km/h Reverse 1 0-16 km/h Grade ability 28° Hydraulic torque converter single stage,4 elements Transmission planet-type Raise time ≤6.8 s Total ≤12.5 s Tire type 23.5-25   20 pr Engine Engine model weichai wd10g220e23 cummins 6cta8.3-c215 Rated power 162 kw Rated rotate speed 2000 r/min Max. torque ≥745.3 n.m Breakout force 145 kn

3 Ton front end wheel loader Bucket Capacity: 1.7 m3 Operating Weight: 10100 kg Rated Power: 92 kw Features: 1.electronic transmission  2.joystick controller  3.radio, driving recorder, reversing image; 4.suspension seat 5.air-conditioner Specifications Model ITQ935 Specifications Operating weight 10,100 kg Rated load 3,000 kg Bucket capacity 1.7 m³ Overall length 7200 mm Overall width 2350 mm Overall height 3200 mm Wheel base 2850 mm Track base 1800 mm Min. ground clearance 450 mm Max. dumping height 3400 mm Max.dumping reach 1290 mm Performance Driving speed    Forward 1 0-8 km/h Forward 2 0-13.5 km/h Forward3 0-25 km/h Forward4 0-36 km/h Reverse 1 0-9.5 km/h Reverse2 0-30 km/h Grade ability 28° Transmission counter shaft Raise time ≤6.8 s Fuel tank 180 L Total ≤12.5 s Tire type 17.5-25  Engine Engine model Deutz WP6G125E22 Rated power 92 kw Rated rotate speed 2200 r/min Max. torque 500 n.m Breakout force 98 kn
