2.5 Ton Triple 4.5 m Mast Electric/Battery Forklift with Side Shift

3 ton Electric/Battery Forklift with Curtis Control —AC drive regenerative braking —Handbrake parking brake —Pedal hydraulic service brake —Quick cut-off valve —Lowering speed limit valve —Tilt lock valve -3 ton electric forklift —Overload relief valve Specification  Item Description Unit FB30 Features Power Unit Lithium Battery Drive Mode Sit Type Rated Load Kg 3000 Loade Center Distance mm 500 Lifting Height mm 3000 Weight Deadweight kg 5000 Battery Weight kg 270 Deadweight without Battery kg 4730 Dimension Front Suspension mm 475 Wheelbase mm 1680 Mast Tilt Angle(Forward/backward) 。 6/12 Mast Static Height mm 2100 Free Lifting Height mm 145 Max.Height when lifting mm 4235 Overhead Guard Height mm 2150 Seat Height mm 130 Driver's Height mm 1130 Overall Length (till fork surface) mm 2530 Overall Width mm 1220 Fork Dimension（LxWxH） mm 1220×125×45 Min.Ground Clearance（full load） mm 125 Min.Truning Radius mm 2210 Tire Tie Type - Pneumatic Qty.of Tires（front/rear） - 2×/2 Front Tire Spec - 28X9-15-14PR Rear Tire Spec - 18X7-8-14PR Performance Travel Speed（full load/no load） km/h 13/15 Lifting Speed（full load/no load） mm/s 275/420 Max. Traction Forcefull load/no load kN 15.7/16.2 Gradeability full load/no load % 15/15 Drive System Travel Motor Power KW 16.6(AC) Working Motor Power KW 13.5(AC) Standard Battery (voltage/capacity) V/Ah 80/404 Standard charger specifications (output) V/A 80/100

 Counterbalance 3.5 Ton Mini Electric/Battery Forklift Performance —Very small front suspension design, improved working stability, small self weight, reduced energy consumption, improved endurance —The driving motor is arranged horizontally, and the battery is sunk at the bottom of the vehicle to improve the driving stability —High speed ratio driving axle box assembly is adopted to improve working efficiency, improve climbing ability, reduce energy consumption and noise —New large screen LED instrument, good visibility, intuitive reading, friendly human-computer interface —Ergonomic anti fatigue seat, which can be adjusted at multiple angles according to the driver's needs —The operator can adjust the steering wheel according to his position Safety —AC drive regenerative braking —Handbrake parking brake —Pedal hydraulic service brake —Quick cut-off valve —Lowering speed limit valve —Tilt lock valve —Overload relief valve Specification  Item Description Unit FB35 Features Power Unit Lithium Battery Drive Mode Sit Type Rated Load Kg 3500 Loade Center Distance mm 500 Lifting Height mm 3000 Weight Deadweight kg 5450 Battery Weight kg 270 Deadweight without Battery kg 5450 Dimension Front Suspension mm 480 Wheelbase mm 1680 Mast Tilt Angle(Forward/backward) 。 6/12 Mast Static Height mm 2180 Free Lifting Height mm 150 Max.Height when lifting mm 4235 Overhead Guard Height mm 2150 Seat Height mm 130 Driver's Height mm 1130 Overall Length (till fork surface) mm 2595 Overall Width mm 1220 Fork Dimension（LxWxH） mm 1220×125×45 Min.Ground Clearance（full load） mm 125 Min.Truning Radius mm 2290 Tire Tie Type - Pneumatic Qty.of Tires（front/rear） - 2×/2 Front Tire Spec - 28X9-15 Rear Tire Spec - 18X7-8 Performance Travel Speed（full load/no load） km/h 13/15 Lifting Speed（full load/no load） mm/s 250/360 Max. Traction Forcefull load/no load kN 15.5/15.0 Gradeability full load/no load % 15/15 Drive System Travel Motor Power KW 16.6(AC) Working Motor Power KW 13.5(AC) Standard Battery (voltage/capacity) V/Ah 80/404 Standard charger specifications (output) V/A 80/100

4X4WD Rough Terrain Forklift Truck with Japanese Yanmar Engine Advantages of rough terrain forklifts: 1. Adopt four-wheel drive. 2. The chassis is high. 3. It can work on ordinary roads, and can also work on rough roads on mountain roads and mud roads. The tires have strong grip and do not slip. 4. The engine is powerful, and it adopts all-wheel drive and off-road tires. 5. It can run on hills, mountains, beaches, sand, snow, ice and muddy roads, and has good off-road performance. Specifications: Specifications Power Unit Diesel Operator Type Driver/Seat Transimission Bo× Type Automatic Transmission Rated Capacity kg 3500 Load Center mm 500 Max.Lifting Height mm 3000 Tire Type Tire Size Front 12-16.5-10PR Rear 12-16.5-10PR Performance Lifting Speed Loaded mm/s 420 Lowering Speed Loaded mm/s 600 Unloaded 300 Traveling Speed Unloaded mm/s 22 Service brake Hydraulic - Pedal Parking brake Mechanical - Manual Max.Gradeability (Loaded) % 16 Front suspension mm 590 Minimum turning radius 2910 Mast Tilting Angle (Fwd/Bwd) deg 5/15 Dimensions Wheelbase mm 1840 Wheel base (front/rear) mm 1250/1320 Minimum ground clearance mm midpoint of the wheelbase 250 Over Length mm 3090 Over Width mm 1600 Overhead Guard Height mm 2450 Fork Size (L×W×T) mm 45x150x1070 Mast Height (Fork lowered) mm 2235 Battery (Voltage/Capacity) V/Ah 12/80 x 2 pcs Truck Weight kg 5100 Engine Brand  Model YN4H055-34VE Rated Power kw/rpm 36.8/2400 Rated torque n-m/rpm 185/1600-1800 Displacement L 2.543

Engineering & Construction Machinery 51.5 ton Crawler Excavator for Sale *High-end first-class core configuration Isuzu engines comply with Stage III emissions, saving fuel and energy. International brand main pump and main valve World-brand hydraulic components ensure high reliability of the hydraulic system *Greater reliability and durability Rugged, high-strength body Reinforced boom, stick, and bucket structural parts *More coordinated comfort Highly rigid new cab, quiet and comfortable Color LCD monitor for convenient monitoring and maintenance Various working modes and optional sizes Specifications MODEL Unit ITQ 520.9 Operating weight  Ton 51.5 Bucket capacity  m³ 2.8-3.6 Engine model ISUZU 6WG1 CUMMINS QSM11 Rated power  kw/r/min 300/1800 299/1800 Volume of fuel tank L 650 Travel speed km/h 4.8/3.0 Swing speed r/min 8.6 Max climbing degree ° 70 Bucket digging force at power max ISO KN 298 Average grounding pressure KPA 86 Hydraulic pump model    InLine  V90N230DP K5V212DPH Maximum flow  L/min 414x2 385*2 Setting pressure  MPa 37 Volume of hydraulic tank  L 335 A  Overall length  mm 11600 B  Overall width mm 3340 C  Overall height （to top of boom） mm 4050 D  Overall height （to top of cab） mm 3280 E  Counterweight ground clearance  mm 1300 F  Min. ground clearance   mm 720 G  Tail swing radius mm 3845 H  Track grounding length  mm 4360 J  Track length mm 5390 K  Track gauge mm 2740 L  Track width mm 3340 M  Track shoe width mm 600 N  Turntable width  mm 3240 O  Max. digging height  mm 10000 P  Max. dumping height mm 6760 Q  Max. digging depth  mm 6260 R  Max. vertical wall digging depth mm 5620 S  Max. digging depth for 2.5m horizontal plane mm 6070 T  Max. digging reach  mm 10580 U  Max.digging reach at ground level  mm 10360 V  Min. swing radius   mm 4825 W  Max. height at min swing radius mm 9250 X Distance from swing center to rear  mm 3845 Z  Height of counterweight  mm 2860 A1 Grounding length (in transportation) mm 6520 Arm length  mm 2550 Boom length  mm 6560

Earth-Moving Machinery 22 Ton New Excavator *High-end first-class core configuration Yanmar engines comply with Stage III emissions, saving energy and fuel. International brand main pump and main valve World-brand hydraulic components ensure high reliability of the hydraulic system *Greater reliability and durability Rugged, high-strength body Reinforced boom, stick, and bucket structural parts *More coordinated comfort Highly rigid new cab, quiet and comfortable Color LCD monitor for convenient monitoring and maintenance Multiple operating modes available Specifications MODEL Unit ITQ 215.9 Operating weight  Ton 22.5 Bucket capacity  m³ 0.93 Engine model 三菱4M50 Rated power  kw/r/min  118/2000 Volume of fuel tank L 420 Travel speed  km/h 5.2/3.5 Swing speed r/min 11.5 Max climbing degree ° 70 Bucket digging force at power max  ISO KN 157 Average grounding pressure KPA 48 Hydraulic pump model   InLine  V90N130 Maximum flow  L/min 222*2 Setting pressure MPa 37 Volume of hydraulic tank L 246 A  Overall length mm 9560 B  Overall width mm 2980 C  Overall height （to top of boom） mm 3040 D  Overall height （to top of cab） mm 3120 E  Counterweight ground clearance  mm 1065 F  Min. ground clearance   mm 466 G  Tail swing radius mm 2720 H  Track grounding length  mm 3260 J  Track length mm 4060 K  Track gauge mm 2380 L  Track width  mm 2980 M  Track shoe width mm 600 N  Turntable width  mm 2700 O  Max. digging height mm 9275 P  Max. dumping height mm 6560 Q  Max. digging depth  mm 6515 R  Max. vertical wall digging depth mm 5915 S  Max. digging depth for 2.5m horizontal plane  mm 6380 T  Max. digging reach mm 9865 U  Max.digging reach at ground level  mm 9680 V  Min. swing radius   mm 3630 W  Max. height at min swing radius mm 7670 X Distance from swing center to rear mm 2720 Z  Height of counterweight  mm 2120 A1 Grounding length (in transportation) mm 4850 Arm length  mm 2900 Boom length  mm 5700

 Heavy Duty Equipment Brand New 35 Tons Heavy Excavator *High-end first-class core configuration Comply with Stage III emission Cummins engine, with excellent power The Isuzu engine complies with Stage III emissions, saving fuel and energy. International brand main pump and main valve World-brand hydraulic components ensure high reliability of the hydraulic system *Higher reliability and durability Greater reliability and durability Rugged, high-strength body Reinforced boom, stick, and bucket structural parts *More coordinated comfort Silent, comfortable and highly rigid new cab Color LCD monitor for convenient monitoring and maintenance Multiple operating modes available Specifications 规格型号 Model  ITQ 360.8 斗容Bucket capacity (m3) m³ 1.6/1.8 整机总质量Operating weight (T) kg 35000 油箱容积 Volume of fuel tank (L) L 595 发动机Engine 品牌型号 Brand Dongfeng Cummins 6LTAA8.9 ISUZU 6HK1X 功率Rated power (kw/r/min) kw/rpm 242/2000 190.5/2000 进气方式Intake mode 涡轮增压Turbocharged 燃油系统工作方式Fuel system mode 直喷Direct injection 排放标准Emission standard 欧ⅡEuro II 底盘Chassis 驱动方式Drive mode 液压Hydraulic 主泵Main pump 品牌型号Brand KPM  K5V160DT 额定压力Rated pressure Mpa 37 流量Flow L/min 320×2 回转马达Swing motor 品牌型号Brand InLine  HM5X180CHB 工作压力Rated pressure MPa 26.5 行走马达Travel motor 品牌型号Brand KYB RT60T/HYUNDAI HT33A 工作压力Rated pressure MPa 34.3 主控阀Control valve 品牌型号Brand InLine  HVME270B                           额定流量Rated flow L/min 300 制动形式Brake form 液压Hydraulic 液压油Hydraulic oil 标号及用量Model and dosage Kg HM046/310 底盘件Chassis parts 履带形式-Track form 三齿Three teeth 履带板宽度Track width ㎜ 600mm 履带板数量No. of track 件 每侧  49(Each side) 履带接地比压Average grounding pressure(KPa) KPa 67.8 支重轮数量No. of track rollers 件 每侧 9(Each side) 性能参数Performance parameter 爬坡能力Max climbing degree° 度 35 行驶速度Travel speed  km/h 3.3/5.2 最大挖掘深度Max. digging depth mm 7370/6890 最大挖掘半径 Max. digging radius mm 11100/10800 最大卸载高度Max. dumping height  mm 7135/6830 最大挖掘高度Max. digging height mm 10200/9800 铲斗挖掘力Bucket digging force kN 227 回转速度Swing speed r/min 10.6 电器Electric appliance 电气系统厂家Manufacturer 临沂科锐KERUI(China) 仪表显示Monitor GPS终端GPS

Brand New Wheel 32 Ton Forklift Loader Feature: 1.The Z-shaped link mechanism designed especially for stone operating conditions features high breakout force and loading capacity and the classic double-rocker structure ensures a broad operating view. 2.The extended wheelbase and wheel tread and ultra-high ballast realize good working stability of the front loader forklift. 3.The China-lIl engine, high reliability electronic control counter shaft transmission, and the reinforced dry-type drive axle are matched perfectly to save the fuel and reduce the consumption. 4.The higher dumping height and dumping distance, extensive rotation angle scope of forks, and adjustable fork spacing are suitable to diversified operation needs, including the forklifting and overturning of stones. 5.The 23.5-25 24PR engneering tires are suitable to diversified severe road conditions, featuring powerful off-road performance. The optional tire chains are at your choice. 6.The high ground clerance,small tuming radius, and high depature angle of the class is can adapt to various complicated operation conditions. Specification: Model ITQ32T Operating weight 34,000kg Engine model WD10G270E201 Rated engine power 199kw Rated rotate speed 2200r/nin Max.torque 1100N.m Max.dumping height 3100mm            Rated load 32tons @3100mm height, NO.of shifts Forward 4 For Reverse 2 Forward/Reverse 1 0-6.5km/h Forward/Reverse 2 0-12.3km/h Forward 3 0-24km/h Forward 4 0-41km/h Grade ability ≥25° Turning angle 35°±1° Overall length 10100mm Overall width 3220mm Overall height 3730mm Wheel base 4300mm Track base 3197mm dimension of fork 1500*mm200*mm120mm Torque converter Model: YJ375X3 ratio:3.166 Cycling time 16s Tire type 29.5-25

Construction New Manufacture Custom 24 Tons Hydraulic Mining Diggers *High-end first-class core configuration Comply with Stage III emission Cummins engine, with excellent power The Isuzu engine complies with Stage III emissions, saving fuel and energy. International brand main pump and main valve World-brand hydraulic components ensure high reliability of the hydraulic system *Higher reliability and durability Greater reliability and durability Rugged, high-strength body Reinforced boom, stick, and bucket structural parts *More coordinated comfort Silent, comfortable and highly rigid new cab Color LCD monitor for convenient monitoring and maintenance Multiple operating modes available Specifications MODEL Unit ITQ 240.9 Operating weight  Ton 24 Bucket capacity  m³ 1.2 Engine model  康明斯QSB7.0 Rated power kw/r/min  142/1950 Volume of fuel tank L 420 Travel speed  km/h 5.2/3.5 Swing speed r/min 11 Max climbing degree ° 70 Bucket digging force at power max ISO KN 172 Average grounding pressure KPA 49.4 Hydraulic pump model KPM  K3V112DT Maximum flow  L/min 228x2 Setting pressure  MPa 37 Volume of hydraulic tank  L 246 A  Overall length mm 9850 B  Overall width mm 2980 C  Overall height （to top of boom） mm 3190 D  Overall height （to top of cab） mm 3120 E  Counterweight ground clearance mm 1065 F  Min. ground clearance   mm 440 G  Tail swing radius mm 2810 H  Track grounding length  mm 3640 J  Track length mm 4450 K  Track gauge mm 2380 L  Track width mm 2980 M  Track shoe width mm 600 N  Turntable width  mm 2700 O  Max. digging height mm 9310 P  Max. dumping height  mm 6440 Q  Max. digging depth mm 6875 R  Max. vertical wall digging depth  mm 5860 S  Max. digging depth for 2.5m horizontal plane mm 6680 T  Max. digging reach  mm 10170 U  Max.digging reach at ground level  mm 9990 V  Min. swing radius  mm 3975 W  Max. height at min swing radius mm 7775 X Distance from swing center to rear  mm 2810 Z  Height of counterweight  mm 2120 A1 Grounding length (in transportation)  mm 5360 Arm length  mm 3050 Boom length  mm 5850
