Japanese Style C Series 7 Ton Diesel Forklift

  • Item no.:

    C FD70T
  • Payment:

    L/C T/T Western Union
  • Product origin:

    CN
  • Color:

    Red/Yellow/White/Blue/Custom Colors
  • Shipping port:

    Xiamen,CN
  • Lead Time:

    25-45 Days
Products Description

Popular Style 7 Ton Diesel Forklift with Cascade Side Shift

7 tons forklift


-Wide view mast

Load backrest

Super hydraulic lifting system

Standard backrest and fork arm carrier

Combined switch

Combined instrument(fuel gauge,water temperature gauge,hourmter,engine oil pressure warming indicator,neutral safety indicator,preheating indicator)

7 tons forklift Adjustable steering wheel

Radirtor reserve water tank

Oil temperature cooler

Backward buzzer

Neutral safety switch

Back view mirror

Luxury suspension seat

Full hydraulic power steering

Toolbox



Specifications:

Model UNIT FD70T
Specifications Power Unit
Diesel
Operator Type
Driver/seat
Transmission Box Type
Electronic hydraulic transmission
Rated Capacity kg 7000
Load Center mm 600
Max.Lifting Height mm 3000
Tire Type
Pneumatic Tyre
Tire Number  Front
4
Rear 2
Tire Size  Front
8.25×15-14PR
Rear
8.25×15-14PR
Performance Lifting Speed Loaded mm/s 450
Unloaded 500
Lowering Speed  Loaded mm/s 500
Unloaded 450
Travelling Speed  Loaded km/h 25
Unloaded 30
Max.Gradeability (Loaded) % 27
Max.Drawbar Pull (Loaded) kg 5400
Mast Tilting Angle (Fwd/Bwd) deg 6/12
Free Lifting Height mm 155
Turning Radius mm 3370
Dimensions Overall Length (with fork) mm 4870
Overall Width mm 2000
Overhead Guard Height mm 2480
Fork Size (LxWxT) mm 1220x150x65
Mast Height (Fork lowered) mm 2500
Battery (Voltage/Capacity) V/Ah 2×12/90
Truck Weight kg 9200
Fuel Tank Capacity L 135
Engine Brand
ISUZU MITSUBISH CHAOCHAI
Model
6BG1 S6S-T 6102
Rated Power kw/rpm 82.3/2000 67.6/2300 80.8/250
Rated torque n-m/rpm 418/1500 293/1700 354/1650
Number Of Cylinder
6 6 6
Displacement
6.49 4.99 5.78
